Intralogistics (IL) AMR

Move More Inventory. Quickly. Efficiently. Safely.

In today’s tight labor market, hiring warehouse workers has become a difficult and costly process. At the same time, manual fulfillment processes are slow and inefficient and forklifts can pose significant injury and inventory damage risks.

To address these challenges, GreyOrange offers an Intralogistics solution that can automate labor-intensive workflows related to material and pallet movement in your warehouse. The Ranger Intralogistics robot (RIL), powered by GreyMatter multiagent orchestration, is a highly adaptive autonomous mobile robot (AMR).

Get started

Ranger Intralogistics Applications

Replace long-haul forklift moves between inbound dock and deep-storage areas.

Automate movement to forward-pick areas. Hand off or take away pallets to and from put/pick operators.

Increase throughput by picking directly to pallets on RIL bots in brownfield warehouses.

Replace forklift-based operations, augment overloaded conveyor-based systems and avoid costly infrastructure investments.

Set and forget trash and empty pallet return flows to keep your facility uncluttered and organized per 5S.

Handle large-item returns, sorting payloads from the returns dock to the correct area.

Key Benefits

Reduce operating costs

by 50-60%

Accelerate dock-to-stock and pick-to-dispatch

2x faster

Fast order-to-commission time

8-12 weeks

Rapid ROI

6-18 months

Customer Success: Sodimac optimizes material movement with the world’s largest pallet-moving AMR installation

1M sq.ft. facility in Chile servicing a chain of home improvement stores, receiving 4,000 single SKU pallets and dispatching 4,000 mixed SKU pallets per day

63 AMRs
0.7M sq.ft. covered by RIL bots
4000 pallets/day orchestrating 13 material flows
Fully integrated with WMS, RTP and third-party conveyor systems
70% reduction in forklifts

RIL Variant & System Components

Ranger Uplift – L (RU-L)

Dimensions	1280 x 920 x 350 mm	51.2 x 36.2 x 13.8 in.
Max Payload	1000 kg	2204 lbs.
Max Speed	2 m/s	4.5 mph
Payload Type	Closed pallets, open pallets, pallet boxes, gaylords, moveable racks, trolleys

Ranger Forklift Elevate (RF-E)

Dimensions	1600 x 900 x 2100 mm	63 x 35.4 x 82.7 in.
Max Speed	1.50 m/s	3.4 mph
Max Payload	1400 kgs	3080 lbs.
Payload Type	Closed pallets (from an elevated pick up), open pallets (from ground), pallet boxes, gaylords, moveable racks, trolleys

Ranger Forklift – AnyPallet (RF – AP)

Dimensions	2035 x 2004 x 983 mm	80.12 x 78.90 x 38.70 in.
Payload	Up to 2000 Kgs	Up to 4410 lbs.
Speed (with/without load)	1.4/1.7 m/s	3.1/3.8 mph
Payload Type	Closed Pallets (From Ground), Open Pallets (From Ground), Pallet Boxes, Gaylords, Moveable Racks, Trolleys

Ranger Forklift – XXL (RF – XXL)

Dimensions	2200 x 2929 x 980 mm	86.61 x 115.32 x 38.58 in.
Fork Length	2450 mm	96.46 in.
Payload	Up to 3000 Kgs	Up to 6610 lbs.
Speed (with/without load)	1.4/1.7 m/s	3.1/3.8 mph
Payload Type	Lift up to 4 Trolleys (from Ground), Lift up to 2 Pallets (from Ground), Lifting Multiple Empty Pallets from De-stackers
